8K professional processor S928X-K

4G DDR+64G eMMC

Dolby Vision   HDR10+

Dolby+DTS Dual certification

FunplayUI 2.0 system

Amlogic S928X-K

ARM Mali-G57 MC2

4G LPDDR4X

64G eMMC

AKM 4432

USB3.0*1，USB2.0*1，Type-C*1

2.4G+5G Dual band WiFi6

10/100/1000Mbps

Built-in NXP dual low ripple power supply

FunplayUI 2.0 based on Android 11

HDMI2.1a; 8K@60fps, 4K@120fps

Dolby Vision, HDR10+, HDR10,

HLG 12Bit Color depth, BT2020 Wide Color gamut

Dolby, DTS   PCM up to 192Khz

HDMI Output

Vrms(±0.1Vrms)

SNR: >103dB@1kHZ

DNR: >97dB@1kHz

CROSSTALK: >95dB@1kHz Frequency response: -1~+0.3dB(20Hz-20kHZ)

Analog Audio

H.265/AV1/VP9/AVS3/AVS2@8K60fps

Dolby Vision, HDR10, HDR10+, HLG

Audio decoding

Coaxial Output

Control

Power

Dimension

Dolby, DTS PCM up to 192Khz

BT remote control, RS232, HDMI CEC, LAN, Smartphone APP

100V-240V~50-60Hz

188mm X188mm X28mm（Exclusive of feet）

CPU

GPU

Memory

Storage

DAC

USB

Wi-Fi

LAN

Power Supply

System
